Description
The model PPM-S230A strain gauge pressure sensor is designed for most general industrial applications. It offers wide measuring range from 0…1MPa to 0…200MPa in all common engineering units. It features good long-term stability, high accuracy and nice repeatability.OEM accepted.
Features
Applications
PPM-S230A strain gauge pressure sensor is widely used in testing machine, engine test, hydraulic system, brake system,water supply system, and other industrial automation equipment.
Specification
| Measuring medium | Gas, liquid |
| Pressure type | Gauge pressure(G), Sealed pressure(S), |
| Pressure range | 0～1MPa…200MPa |
| Power supply | 3～15VDC（5VDC suggested） |
| Output signal | 1.5 mV/V ,2.0 mV/V,3.3mV/V(0~7.5mV,0~10VmV,0~15mV at 5VDC power supply) |
| Nonlinearity | 0.05%, 0.06%, 0.08% |
| Repeatability | 0.1% |
| Creep | 0.03%FS |
| Accuracy | ±0.25%FS,±0.5%FS |
| Long-term stability | 0.2%FS/year |
| Operation temp | －25～85℃ |
| Zero temp. drift | ±0.02%FS/℃ |
| FS temp. drift | ±0.03%FS/℃ |
| Response time | 1 ms |
| Output impedance | 350Ω、1600Ω、2000Ω |
| Insulation resistance | ≥1000 MΩ/100V |
| Overpressure | 150%FS （1.5 times FS） |
| Damage pressure | 500%FS （5 times FS） |
| Vibration resistance | ＜0.1%FS,at 5～1000Hz,2mm amplitude,X Y Z each direction in 30 minutes |
| Impact resistance | ＜0.1%FS，at50g；X、Y、Z each direction 20ms； |
| Process connection | M20×1.5,M16×1.5,M14×1.5,M10×1,G1/4 or other on request |
| Materials | Diaphragm：17-4PH stainless steel, Thread parts：1Cr18Ni9Ti stainless steel |
| Humidity | 0～95% RH |
| Ingress protection | IP67 |
| Electrical connections | Cable connection |
Definition of wiring:
Dimensions
